Wagner Competition Intercooler Kit EVO3 for BMW 335d E90, E91, E92 & E93

Maximum cooling performance for BMW 335d E90, E91, E92 & E93 - Wagner Tuning Competition Intercooler Kit EVO3

The Wagner Tuning Competition Intercooler Kit EVO3 has been specially developed for the BMW 335d E90, E91, E92 & E93. With a 133% larger inflow area and 183% more charge air volume, it significantly improves cooling performance and increases engine power.

Innovative racing technology for maximum performance

The high-performance mesh with bar-and-plate technology ensures optimum heat transfer and reduces back pressure. The CFD-optimized aluminium end boxes ensure even airflow and increase the efficiency of the engine.

Technical advantages:

• 133% larger inflow area - More effective heat dissipation for constant temperatures
• 183% more charge air volume - Optimized air supply for improved engine performance
• Inlet and outlet Ø70 mm - Increased air flow for maximum efficiency
• Optimized flow dynamics - Reduced flow resistance for greater efficiency
• Anti-corrosion coating - Protection against external influences & extended durability
• Plug & Play installation - Minimal adjustments required

Dimensions in comparison:

• OEM intercooler: Volume: 7.29 L | flow area: 663 cm²
• Wagner Tuning Intercooler: Volume: 20.65 L | flow area: 1545 cm²

Suitable for the following models:

• BMW 335d E90 (2005-2013) *
• BMW 335d E91 (2005-2013) *
• BMW 335d E92 (2005-2013) *
• BMW 335d E93 (2005-2013) *

* Note:

• Modifications to the vehicle required (see installation instructions)
• Only suitable for vehicles without ACC unit

Scope of delivery:

• 1x intercooler (black coated)
• 3x reinforced silicone hoses
• 1x aluminium adapter (black anodized)
• 1x aluminium charge air pipe (black anodized)
• 1x mounting material
• 1x assembly instructions

Note:

• Professional installation recommended
• Not approved in the area of the StVZO
